14
17
Unscrew the pre-assembled nut of the Ignition Button (C8).
Insert the Ignition Button (C8) into the hole at the side burner shelf and secure with the pre-
assembled nut.
Connect the electrode wire to the ignitor.
WARNING: BEFORE OPERATION, ENSURE SIDE BURNER WIRES ARE CONNECTED TO
IGNITOR. IF THE CIRCUIT IS NOT COMPLETED, THE IGNITOR WILL NOT SPARK!
18
Place the Side Burner Grid (C6) onto the side
burner shelf.
NOTE: Make sure the base of cooking
utensil to put on the side burner is larger
than 150mm and smaller than 240mm.
C8
C6
B9
Insert the Drip Tray (B9) by sliding it underneath
the barbecue body.
To Next Page
