Parts List
Quantities vary according to model purchased. Specifications subject to change without prior notice. For more
details on hardware, please see ‘Hardware Reference Diagram’.
Pre-Assembled Component
Quantity varies according to model purchased
Appearance, size, and construction may differ according to model purchased
CODE PART QTY
Society/
Granite
Manhattan/
Graphite
Monarch/
Mercury
LID
A1 Lid Handle 1
A2 L/H Lid Handle Bracket 1
A3 R/H Lid Handle Bracket 1
A4 Flat Lid (Pre-Assembled to Body) 1
BODY
B1 Barbecue Body 1
B2 Burner
2 3 6
B3 Burner Clip
2 3 6
B4 Control Panel 1
B5 Knob
2 3 6
B6 Drip Tray 1
B7 Drip Pan 1
B8 Foil Liner 1
B9 Lava Rock Basket 2
B10 Lava Rock Pack (in Basket) 2
B11 Grill with Cutout
2 1 1
B12 Grill 1
B13 Griddle with Cutout 1
B14 Warming Rack 1
B15 Hose 1
TROLLEY
C1 L/H Side Shelf 1
C2 Side Shelf Shield 1
C3 Front Left Endcap 1
C4 Rear Left Endcap 1
C5 Utensil Tray 2
C6 R/H Side Shelf 1
C7 R/H Insert 1
C8 Front Left Leg 1
C9 Rear Left Leg 1
C10 Front Right Leg 1
C11 Rear Right Leg 1
C12 Bottom Slat Assembly 1
C13 Base Tray 1
C14 Gas Bottle Holder 1
C15 Trolley Foot 1
C16 Hubcap 2
C17 Wheel 2
C18 Locknut 2
C19 Axle 1
C20 Retaining Rod 1
C21 Gas Bottle Strap 1
HARDWARE
D1 Countersunk Screw, M4x15 4
D2 Screw, M6x15 24
D3 Washer 4
D4 Screw, M6x35 16
