Attention! When the software indicates the array is
out of range (as in figures 6 and 7), it could be neces-
sary to:
• reassess the overall inclination of the array in
case the center of gravity is out of range;
• remove some line array elements because the
maximum limit weight has been exceeded;
• both of the above.
These cases can also occur with ground stack con-
figurations (figure 8).
figure 6
figure 7
figure 8
