3.3 Operating elements and displays
The flow rate is set and regulated with the
help of the regulating inserts.
1
2
3
4
5
6
Fig. 3: Design of the regulating insert
1
Adjustment screw
2
 mm hexagon socket
3
 mm hexagon socket
4
Valve spindle
5
Valve open
6
Valve closed
