Page 24
Click on the start button and then Control Panel.
Step
3
Stripe (RAID 0) - Two volumes will mount on your desktop, each made
up of a high-speed RAID-0 Stripe - combining two volumes each. Using
a RAID-0 Stripe format, if you had 4 1TB drives in your OWC Mercury
Elite 4 Bay RAID Rack, you would have 2 2TB volumes mount on your
desktop.
(IMPORTANT) Realize that reconguring your RAID will destroy
all data on this storage enclosure. Be sure you have a backup
before proceeding. Make sure that the power is turned o.
Step
1
Step
2
Look at the back of the OWC Mercury Elite 4 Bay RAID Rack and
locate the switches to the right of the USB port. Make sure they
are both on the “RAID 0” position (RIGHT).
Setup your OWC Mercury Elite 4 Bay RAID Rack as RAID 0
(2 striped hard drives) on a PC (Windows XP / Vista)
