Note: For the 4000 uF range, the measuring duration should be over 30 seconds.
(1) Rotate the rotary switch to . Press three times to enter capacitance
measuring mode, the Farad units will be displayed.
(2) Connect the black test lead to the terminal and the red test lead to the
terminal.
(3) Probe the test points and read the display.
Measuring Frequency
Frequency ranges are 9.999 Hz, 99.99 Hz, 999.9 Hz, 9.999 kHz, 99.99 kHz, 999.9 kHz, and
9.999 MHz.
(1) Rotate the rotary switch to .
(2) Connect the black test lead to the terminal and the red test lead to the
terminal.
(3) Probe the test points and read the display.
(4) Press to switch between the frequency and duty cycle measurements.
When measuring AC voltage or AC current, press to cycle through frequency
measuring, duty cycle measuring, and original measuring.
Measuring Transistor
more than 250Vdc or 250Vac rms between the
terminal and
the
terminal.
(1) Rotate the rotary switch to .
(2) Connect the “+” plug of the multi-functional test socket to the terminal
and the “COM” plug to the terminal).
(3) Determine whether the transistor is NPN or PNP type and locate the Emitter, Base
and Collector leads. Insert leads of the transistor into the corresponding holes of the
multi-functional test socket.
(4) Read the hFE value.
Measuring Temperature
(1) Rotate the rotary switch to .
To Next Page
