By default, the pitch of the first voice (or track if it’s a Multitrack mode sequencer) is selected when
activating one CV or the Gate of the first voice/track when activating one Gate.
The selection is remembered if you change the sequencer source but it’s cleared when you remove
the sequencer.
Pitch routing
Each Sequencer mode has a different amount of voices available that you can route to the CVs and
Gates:
· Mono 1 voice
· Chord up to 8 voices
· Polyphonic up to 7 voices
· Multitrack up to 8 voices (1 per track)
Pitch, Gate, Velocity and Trig Envelopes modulation sources are correlated by voice number.
After selecting one of these sources you can choose which voice it reads from with the first encoder,
for example:
If the cv is set to pitch, the second parameter offsets the note per semitones and the fourth parameter
specifies the cv voltage format.
To carry a typical modular voice you need to choose the same Sequencer and voice number for Pitch
and Gate, velocity and Trig Envelope.
Example: to output three independent chord voices in the sequencer 2, if we start from the mostleft
CVs and Gates, the CV routing layout will look like this:
