Oxy Heli OXY 3 - Chapter 12: Flybarless Installation; Flybarless Installation

Double - Side Tape
Flybarless Unit
Servo Ports
Forward
For extra FBL support we
suggest to add Electronic
Hook and Loop as shown.
Step 1 Step 2
Page 17
The FBL system can be
installed at the bottom or
top of the boom clamp.
We suggest to use the
bottom for easy wiring
and servo removal.
Chapter 12, Flybarless Installation
Instruction Manual Rev 1
