Oxy Heli OXY 3 - Adjustment Servos with Leveler

90°
90°
90°
Page 35
Step 4
Step 5
After removing Leveler, the position of
servo arms as shown.
Lift Swash Plate down untill Swash Plate
touch Leveler as shown.
Left heli side Front heli side
Left heli side
Chapter 20, Adjustment Servos with Leveler
Instruction Manual Rev 1
