Oxy Heli OXY4 - Chapter 16: Tail Servo Installation

Chapter 16: Tail Servo Installation
page 31
Optional Tail Servo Installation
2 x TBES2X6 - M2x6
Self Tapping Screw
2 x M2 Washer
2 x TBES2X8 - M2x8
Self Tapping Screw
OXY0717 - PL
Tail Servo Support
Tail Push Rod Asembly
Micro Servo Assembly
Mini Servo Assembly
2 x TBES2X8 - M2x8
Self Tapping Screw
4 x TBES2X8 - M2x8
Self Tapping Screw
