Chapter 17: Landing Gear & Battery Installtion
page 33
Landing Gear & Battery Installtion
Battery Straps
( Accessories Bag )
Landing Gear Skid
Main Blades Installation
Tail Blades Installation
Satellite
EX
6 x M2.5x10 Self
Tapping Screw
don't over tighten
M3x18 Hex Cap Screw
325mm Main Blade
M3 Self Lock Nut
Tail Blade
( Box 3 / Bag 8 )
OXY0078 - M2x10
Button Screw
