Oxy Heli OXY4 - Page 37

4.50mm
Chapter 21: Addendum - FBL Head System
page 36
FBL Head System not Included in the kit
2.5X4.2X0.35 Spacer
OXY0080 -Uniball
Radius Arm
2 x SMR628_ZZC - 2.5X6X2.6
Radial Bearing
OXY0089 -
Pin 1.5X9.5
OXY0750-M2x15 Threaded Rod
OXY0716 - linkage Ball
OXY0433 - Link Ball
OXY0434 - Main
Grip Bushing
OXY0055 -
2.6X4.2X0.35 Washer
TBEM2.5x14 - M2.5x14
Button Screw
Self Lock Nut M2.5
TCEM2.5x12 - M2.5x12
Hex Cap Screw
