1. ASSEMBLY
KNOW YOUR PRODUCT
SETUP & PREPARATION
CORDLESS RECIPROCATING SAW
1 2 3 4 5 6 7
1 Timber Cutting Blade
2 Pivoting Shoe (Adjustable)
3 Blade Holder
4 Shoe Locking Button
5 Variable Speed Trigger
6 Sure Grip Handle
7 Lock-Off Button
BATTERY & CHARGER (sold separately)
Compatible chargers
Eco charger PXCSCH-120
“ “ PXCG-120
Fast charger PXCFCH-030
“ “ PXCG-030
Compatible battery packs
1.5Ah PXCBAT-015
“ PXBP-150
3.0Ah PXCBAT-030
“ PXBP-300
5.2Ah PXCBAT-052
“ PXBP-520
1 Rotate and hold the blade
holder anti-clockwise.
1 Rotate and hold the blade
holder anti-clockwise.
3 Ensure the blade is secure by pulling on the blade.
1 Push the shoe locking
button in from the left side
of the saw to unlock the
shoe.
3 Secure in place by
pressing the shoe locking
button in from the right side
of the saw.
2 Remove the blade and
release the blade holder.
2 Insert the blade and
release the blade holder.
2 Push the shoe in or out into
the desired position.
Removing a Cutting Blade
Fitting a Cutting Blade
WARNING! ENSURE THE TOOL IS SWITCHED OFF AND
THE BATTERY IS REMOVED BEFORE PERFORMING ANY
OF THE FOLLOWING TASKS.
Adjusting the Pivot Shoe
