Ozito PXRSS-400 - Operation; Fitting the Battery; Cutting Procedure

4. FITTING THE BATTERY
OPERATION
Inserting & Removing the Battery (not included)
1 Align the ribs of the battery
with the recess at the base
of the saws rear hanlde
and push in until it clicks
into place.
2 Squeeze the on/off trigger
to start operating.
1 Firmly press the pivoting
shoe against the work
piece.
2 To remove, press
and hold the battery
release tab and
then slide out.
1 Press and hold the lock-off
button.
3 To stop the saw, release
the on/off trigger.
2 Start the reciprocating
saw.
3 Keeptheadjustablepivotshoermlyagainsttheworkpiece
thoughout the cut.
Battery protection system
The tool is equipped with the battery protection system, which helps to
ensure a long service life.
The output power automatically cuts off during operation when the tool and/
or battery are placed under the following situations:
• When the tool is overloaded:
If this occurs, release the trigger switch and remove causes of overload,
then pull the switch trigger again to restart.
• When the remaining battery capacity becomes low:
Recharge the battery pack.
Note: The battery protection system does not in any way damage the tool.
Note: The indicated capacity may be lower than the actual level during use
or immediately after using the tool.
5. CUTTING PROCEDURE
PXRSS-400
CAUTION: DO NOT ALLOW THE TOOL TO BOUNCE.
IF THE PIVOT SHOE IS HELD AWAY FROM THE WORK
PIECE DURING OPERATING, STRONG VIBRATION AND/
OR TWISTING MAY OCCUR CASUING THE BLADE TO
SNAP DANGEROUSLY.
Note: The lock-off button can be released once operating
Note: Do not apply excessive pressure, allow the blade to do
the work.
Turning On and Off
Cutting Procedure
