PAC GM3A-RSTX - Installation Steps; Set Radio Select Switch; Default Steering Wheel Control Programming; Default SWC Button Assignments

Radio Replacement and Steering Wheel Control Interface
with OnStar Retention for General Motors Vehicles
GM3A-RSTX
© 2018 AAMP Global. All rights reserved. PAC is a Power Brand of AAMP Global.
PAC-audio.com
Pacific Accessory Corporation
Page 2
Rev: 1
Date: 100318
Installation Steps
1. The radio select rotary switch on the side of the interface must be adjusted to the proper radio
setting before plugging the interface into the vehicle.
2. Make all connections as described in the chart on page 1. Be sure to connect both Yellow wires (one from vehicle harness and one from RP
Advanced harness) and both Black wires (one from vehicle harness and one from RP Advanced harness) while making these connections.
3. Factory installed ampliers will determine the audio output connection. If the vehicle has a factory installed amplier, use the factory
amplier audio location. If a factory installed amplier is not present, use the non-amplied factory audio location.
4. If the vehicle is equipped with a Premium BOSE system, connect the subwoofer and center channel RCA inputs to the aftermarket radio. If
the aftermarket radio to be installed does not have a dedicated center channel or sub output, do not use this cable. To ensure best sound
performance, channel summing is not recommended. Use this cable according to the outputs that are available.
5. If the vehicle is equipped with a reverse camera and the aftermarket radio has a reverse camera input, connect the Yellow RCA plug on the
Brown connector to the aftermarket radio’s reverse camera input.
6. If the aftermarket radio is equipped with an auxiliary input and you wish to retain the factory XM tuner, plug the RCA connectors from the
interface into the radio’s auxiliary input.
7. Plug the CMX chime module in if necessary (If the vehicle chimes when the radio is removed, the CMX is not necessary). PLEASE NOTE:
In order to get the best possible sound out of the CMX, please mount it in a place free and clear of any obstructions, preferably as close as
possible to the bottom of the dash pointing down toward the oor of the vehicle.
8. The Mute loop (if not cut) will turn the accessory output off when an OnStar or Bluetooth call is made or received. If the aftermarket radio
has a mute input cut this loop and connect the inner Brown wire (next to the Blue / White wire) to the mute input.
9. Connect the SWC wire according to the chart on page 1 (aftermarket radio MUST support a wired remote input).
10. If you wish to reassign functions to the SWC follow the programming instructions in the next section.
IMPORTANT! The interface comes pre-programmed for the functions listed in the chart below and does not require programming
unless you wish to re-assign the SWC functions, or utilize short press long press dual command functionality. The SWC can
always be restored to default settings by pressing the program button on the side of the interface once and waiting for the timeout.
Alpine JVC Kenwood Clarion Pioneer Sony Fusion
Volume +
Volume + Volume + Volume + Volume + Volume + Volume + Volume +
Volume -
Volume - Volume - Volume - Volume - Volume - Volume - Volume -
Source
Source Source Source Source Source Source Source
Track +
Track + Track + Track + Search + Track + Track + Track +
Track -
Track - Track - Track - Search - Track - Track - Track -
Voice
Voice Voice Voice Voice Voice Voice Mute
Play/Pause
Preset + Preset/Disc - Disc/FM+ Band Preset + Preset + Audio
Default Steering Wheel Control Programming
Default SWC Button Assignments
Optional Steering Wheel Control Programming
If you wish to re-assign the SWC functions, utilize short press long press dual command functionality or select between Factory/
Aftermarket mode, the interface must be programmed in the specic order shown in the chart on page 4. If you come across a
function in the chart that your steering wheel does not have, or you do not want to program, press and release the program button
on the side of the interface to skip that function. The LED will ash off and on conrming that you have successfully skipped that
function and are ready to proceed to the next one.
1
2
3
4
5
6
7
8
9
0
Alpine JVC
Kenwood /
Lightning Audio
Clarion /
Nakamichi
Pioneer /
Other*
Sony Fusion
1 2 3 4 7 8 9
*Other - Dual / Axxera, Jensen, Rockford Fosgate
SET RADIO SELECT SWITCH
