Pace TDC787X - Using RF Bypass

20
Using RF Bypass
You can use the RF Bypass feature to watch the regular (analog) channels that are included in the cable service.
It makes these channels “bypass” your set-top and pass directly to your TV and/or VCR. You may wish to do this
if you want to record a different channel on a VCR or DVD recorder.
To use RF Bypass:
• Yourset-topmustbeinstalledwiththecorrectconnectionsfromtherearpaneltoyourTVorVCR(seethe
note,right);and
• TheRFBypassfeaturemustbeon(youmayneedtosetitto“On”intheSetupmenu;seepage36).
A BYPASS light on your set-top’s front panel lights up green if RF Bypass is on. Your remote control may have a
button that allows you to turn Bypass on and off.
For you to start using RF Bypass, your set-top must be turned on. However, once set, RF Bypass works even if you
turn your set-top off.
When RF Bypass is on: you can use your TV’s remote control to tune to any of the available regular (analog)
channels and watch that channel on your TV (the path is the RF cable). You can, at the same time, use your set-
top’s composite video and L and R audio outputs to record on your VCR the channel that your set-top is tuned to.
(This channel number is shown on your set-top’s front panel.*) This means that, when the Bypass is on, you can
watch a regular (analog) channel on your TV and, at the same time, record a digital channel on your VCR.
(If you are recording on the hard disk, you can record two different programs on it, while watching an analog
channel on the bypass.)
When RF Bypass is off: you see on your TV the channel that your set-top is tuned to. This is the same
channel that your VCR receives. Therefore, when RF Bypass is off, you can record on your VCR only the program
that you are watching on your TV (but you can still record a different one on the hard disk).
OPERATING YOUR SET-TOP (cont.)
NOTE
If you are not sure whether your
set-top has been set up to allow
RF Bypass, check your installation.
If there is a cable (RF cable) going
from the TO TV connector on your
set-top’s rear panel to your TV (or
to your VCR and TV, as shown by
the dashed line on pages 12 and
13), then RF Bypass is correctly
set up. Your TV and VCR also
need to have been tuned to your
set-top’s VHF output channel (3 or
4, depending on your location).
NOTE
* If the “Front LED Display” (see
page 36) is set to “Current Time”,
you will not see the channel
number. To see the number of the
channel your set-top is tuned to,
you must set “Front LED Display”
to “Current Channel”.
