SECTION 2 SPECIFICATIONS
15
FIGURE 2.2 OUTPUT RATING CURVES BY MODEL
Rated continuous load current as a function of Power Factor and Output Voltage – Nominal Input Line.
Short term overloads to 120% are permitted. Operating time before thermal shutdown or circuit breaker trip will vary
from seconds to several minutes depending upon line and temperature conditions.
150V Range
300V Range
