Installing battery pack to vacuum unit
1. Ensure vacuum unit power switch is in the
OFF position.
2. Insert battery pack into battery pouch that comes
with your machine. Please check battery pack
has been inserted so that battery level is showing.
3. Ensure it is securely bound in position with
velcro strap.
4. Insert battery connector to vacuum unit socket.
Turn connector clockwise to lock.
Removing battery pack from vacuum unit
1. Ensure vacuum unit power switch is in the
OFF position.
2. Pull tab on connector away from unit.
3. Turn the connector anti-clockwise and remove.
4. Detach velcro strap from vacuum unit.
5. Remove battery pack from battery pouch.
3
Operating Instructions
Battery Level
Support: +618 9479 1444 www.pacvac.com
