11 Inputs
BA700 102-12 – 102-14
Nr. description
IN01.1 Counter Lane 1 B8 white-red
IN01.2 Counter Lane 2 B11 brown-red
IN01.3 Counter Lane 3 B9 white-black
IN01.4 Table lower position, pre switch off B21 yellow pink
IN01.6 Table upper final position B14 brown-black
IN01.7 Table lower final position B15 grey-green
IN01.8 Speed counter infeed belts B7 white-pink
IN01.9 Speed counter flat belts B4 yellow-brown
IN01.10 Pressing bars working position B3 white-yellow
IN01.11 Batch pressure B5 white-grey
IN01.12 Table middle position B18 white-blue
IN01.13 Pusher working position B17 pink-green
IN01.14 Table upper position, pre switch off B20 grey-brown
IN01.15 Counters free B12 pink-brown
IN02.1 Emergency Stop S1 B26
IN02.2 Emergency Stop Q1
IN02.3 Emergency Stop K6 Error
IN02.4 Emergency Stop external (MBO) B28
IN02.5 Hood B30
IN02.6 Hood external (MBO)
IN02.7 Head-Save B25
IN02.8 Emergency Stop driver press
IN02.9 Emergency Stop driver band
IN02.10 Emergency Stop driver table
IN02.11 temperature
IN02.12 K33 function
IN02.13 Error message external (MBO)
IN02.14 START signal B27
IN02.15 STOP - signal B29
IN02.16 Pusher ground position B16 yellow-grey
IN03.1 Heat-sealers ground position B1 white-green
IN03.2 Heat-sealers working position B2 brown-green
IN03.4 Tape END B13 green-blue
IN03.5 Table level while sheet feeding B19 brown-blue
IN03.6 shaft save yellow-blue
IN03.8 S-Pusher position end right B36
IN03.9 Batch table upper position B38
IN03.10 Batch table lower position B37
IN03.11 Pusher ground position B39
IN03.12 Pusher working position B40
IN03.13 S-Pusher position end left B35
