15
Error list TC166
58
Subject to change without notice
15 Error list TC166
Error
nr.
Conditions In- /
Output
Description Possible Causes
04 Machine Start B8/B9/B11 Photocells covered for longer then 2 seconds whilst
press drive is running
Infeed press
1. Paper jam before pressing rollers
2. Photocell or cable defective
05 Machine Start B7 There is no signal transmitted from the slotted disc
initiator B7 to the control system
Drive slip press
1. Drive belt defective
2. Motor/frequency converter M1 defective
3. Sensor B7 defective
06 Machine Start
Single Sheet Operation
B12 The photocell B12 before the shaft, is covered for
longer than 2 seconds whilst the belts are running
1. Paper jam before shaft
2. Single sheet mode selected during stream
delivery operating mode
3. Input IN01.15 problem
4. Photocell wrongly adjusted and sensing
continuously
07 Machine Start
Belt Drive Start
B4/Y24 There is no signal transmitted from the slotted disc
initiator B4 to the control system
1. V-belt defective
2. Motor/frequency converter M2 defective
3. Sensor B4 defective
4. Input IN01.9 problem
09 Machine Start
Packing cycle
B18/B15 Photocell B18 is covered when the elevation table has
moved completely down after bundling
1. Paper jam under pressing bars
2. Vertical belt has slipped off
3. Sensor B15 or sensor/cable B18 defective
10 Machine Start B5/Y18 If elevation table should move upwards (Y18), pressing
sensor B5 is operated.
1. Paper jam under pressing bars
2. Check pressing sensor's mechanical function
11 Machine Start
Packing cycle
B16 After ejecting bundled parcels, the reverse movement
of the ejector last longer than 2 seconds.
1. Paper jam in ejector area
2. Sensor B16 wrongly adjusted or defective
3. Input IN02.16 problem
4. Air pressure too low
5. Throttle D2 adjusted wrongly
12 Machine Start
Packing cycle
Bundling cycle has not been completed before the next
bundling cycle commences.
1. Number of pieces in batch too low
2. Bundling cycle interrupted by a fault
3. The machine's cycle time is exceeded
BA700 102-12 – 102-14 Software: 102F-103.h86
BA900 103-11 – 103-15 BA707-16a
