Palamides 102-13 - Outputs

12
Outputs
50
Subject to change without notice
12 Outputs
BA700 102-12 – 102-14
Nr. description
OUT01.1 Main valve Y2 white
OUT01.2 Knife Y3 grey-pink
OUT01.3 Pusher Y4 violet
OUT01.4 Tape tension Y5 red
OUT01.5 Heat Sealers Y6 blue
OUT01.6 Pressing bars working position Y7 grey
OUT01.7 Stopper Y8 black
OUT01.8 Deflector reject Y9 brown
OUT01.9 Deflector pass through Y10 green
OUT01.10 Batch Clap Y11 yellow
OUT01.11 Cooler Y12 red-blue
OUT01.12 Pressing bars ground position Y14 pink
OUT01.13 S-Pusher left Y25
OUT01.14 Batch table up Y28
OUT01.15 Pusher out Y29
OUT01.16
OUT02.1 Heat-sealing Y17
OUT02.2 Table Start Y23
OUT02.3 Table down Y18
OUT02.4 Table slow speed Y20
OUT02.5 Table high speed Y21
OUT02.6 Error-message Y22
OUT02.7 Flat - belt Start Y24
OUT02.8 Signal Lamp Y34
OUT02.9 Brake K34 Y33
OUT02.10 contactor K8 Y35
OUT02.11 clearing K36 Y36
OUT02.12 stop MBO while installing Y37
OUT02.13 Tape Drive Start Y38
OUT02.14 Tape Drive rewards Y39
OUT02.15
OUT02.16
