14
Code list TC161
54
Subject to change without notice
14 Code list TC161
Code-
Nr.
Password
protected
Set
value
Limit
-
Limit
+
Unit Title Description
100 no Password 1021
102 Program version
103 no 450 300 1000 ms Heating time paper Heating time for paper banding
104 no 1500 500 4000 ms Cooling time paper Cooling time for paper banding
105 Cycle counter
106 yes 400 100 800 ms Heating delay Delay in heating (Y17) depends on B2
107 no 750 100 2000 ms Timing pressing rails In single sheet mode (in the operating position) the start of the
pressing rails is delayed by the set time.
108 yes 0 0 ms Delay 1 Delay in moving elevation table up (Y18) after reaching intermediate
position (B18)
109 yes 0 0 ms Delay 2 Delay in moving elevation table up (Y18) after ejecting the banded
parcels depends on B16
110 yes 1000 0 ms Delay 3 After completing a package cycle, the machine only goes to
destacking mode after this length of time
111 no 10 0 mm Tolerance Tolerance depends on calibrated value
112 no 200 0 mm Direction counter 1 In stream feeding mode, the stream is gathered together for this
length after reaching the pre-selected batch piece value
113 no 130 0 mm Direction counter 2 After reaching the pre-selected batch piece value the elevation
table, in stream delivery mode, only moves to the intermediate
position after this value has elapsed
114 no 80 0 ms Direction counter 3 After reaching the pre-selected batch piece value the elevation
table, in single sheet mode, only moves to the intermediate position
after this time has elapsed
115 yes 1000 0 ms Delay 4 Photocell B19 must be continuously covered for this length of time
so that the elevation table goes down
BA700 102-13B Software: BAx07-16 / TC161
BA900 103- from 15 Software: BAx07-17 /
Check software version:
Code: 102
