15
Error list TC166
60
Subject to change without notice
Error
nr.
Conditions In- /
Output
Description Possible Causes
22 B30 Guard open 1. BA guard open
2. Folding machine guard open
3. Lower banding door of the BA open
4. Cover under the press (BA900) open/released
5. Cover in front of the press (B900) open
6. Cover after the press (BA900) open
7. Input IN02.5 or input IN02.6 problem
8. Wrong adapter used to connect with MBO folding
machine with 18-pin plug
23 Emergency-Off folding machine 1. Error message from the folding machine
2. Input IN02.13 problem
24 Emergency-Off button S1 1. Emergency-Off button on BA 700 pressed or
defective
2. Input IN02.1 problem
25 Emergency-Off protective motor switch Q4 1. Protective motor switch on the jogging drive has
switched off
26 Emergency-Off K6 Emergency-Off contactor K6 malfunction 1. Emergency-Off contactor K6 does not fall away
2. Fuses F10 or F11 defective
3. Power unit defective
4. One of the sensor cables defective
27 Guard open K33 Guard contactor K33 malfunction 1. Guard contactor K33 does not fall away
28 B45 Temperature switch-off of the motors 1. Temperature switch in the motors
Press drive motor too hot
Belt drive motor too hot
Elevation table drive motor too hot
2. Output 02.10 defective
3. Input IN02.11 problem
4. Code 123>50 adjusted
29 Machine Start
Packing cycle
Elevation Table down
B15 Elevation table moves to delivery position and takes
too long
1. There is material under the elevation table
2. Elevation table down does not function
3. Sensor B15 or B21 defective
4. Elevation table motor defective
5. Frequency converter
6. Input IN01.7 problem (B15)
