Error list TC161
66
Subject to change without notice
Error
nr.
Conditions In- /
Output
Description Possible Causes
30 Machine Start
Packing cycle
B14 Elevation table moves to starting position and takes too
long
6. Elevation table system fault (Motor, FRQ, etc.)
7. Parcel between pressing bars & elevation table
8. Sensors B14 or B20 defective
9. Input IN01.6 problem (B14)
10. Elevation table knocks against the jogging plates
(bent)
31 Machine Start
Packing cycle
B2 Time for extending welding die exceeded welding die
moves to working position
5. Paper between the welding dies
6. Air pressure
7. Sensor B2 defective or wrongly adjusted
8. Input IN03.2 problem
32 Machine Start
Packing cycle
B1 Time for retacting welding die exceeded welding die
moves to normal position
7. Defective cylinder
8. Air pressure
9. Obstacle
10. Sensor B1 defective or wrongly adjusted
11. Input IN03.1 problem
12. Linear bearing defective
34 Machine Start
Open Guard
Drives turn at too high a speed during jogging
operation
4. Frequency converter defective
5. Tacho defective
6. Frequency converter set to wrong parameters
35
Destacking without
counter release
B12
Sensor B12 do not aware the product
batch counter does not count,
destacking sensor covered.
2. Sensor B12/B19 defective
3. Sensor B12/B19 not on the product
4. Sensor B12/B19 wrongly adjusted
37 B41 Frequency converter pressing drive has switched off 3. Fault with frequency converter A13
4. Protective motor switch Q3 has switched off
5. Further information on the FU-Display
38 B42 Frequency converter belt drive has switched off 3. Fault with frequency converter A14
4. Protective motor switch Q3 has switched off
5. Further information on the FU-Display
39 B43 Frequency converter elevator table drive has switched
off
3. Fault with frequency converter A15
4. Protective motor switch Q3 has switched off
5. Further information on the FU-Display
