palintest Lumiso Chlorine User Manual

Check Standard Mode:
Verify instrument performance
using NDF check standards
Label Mode:
Assign a label to your measurement
Log Mode:
Access the last 50 measurement
results
QR Log Mode:
Access a QR code that contains
the current log.
Date & Time Mode:
Manually edit the date & time in
the instrument. Date format can
also be changed.
Brightness Control Mode:
Adjust the brightness of the
screen backlight.
15

palintest Lumiso Chlorine Specifications

General

Instrument	Single wavelength, direct-reading colorimeter
Optics	LED light source optical system with narrow band wavelength filters and photodetectors
Test Cells	25 mm diameter tubes
Wavelengths	Automatic wavelength selection of 530 nm
Wavelength Tolerance	± 2 nm
Filter Bandwidth	5 nm
Blank/Zero setting	Held in memory, but instrument will prompt for re-blanking after 50 minutes
LCD Display	226 x 138 pixel with adjustable backlight
Results Log	50 results, with date, time and label
Operating Conditions	0 – 50°C 90% Relative Humidity (non-condensing)
Waterproof Rating	IP67 (Waterproof)
Power Supply	3 x 1.5V AA batteries USB Port 6V max, 200mA max (DC)
USB Port	Micro USB Type B

Weight and Dimensions

Size	163 x 70 x 45 mm
Weight	275g (including batteries)
