palintest Lumiso Chlorine User Manual

Lumiso
Pooltest
A Palintest Product
Lumiso
A Palintest Product
12:28:
4
9
1
6
-
0
7-2
0
21
Lumiso
Pooltest
A Palintest Product
Lumiso
A Palintest Product
12
:
28
:4
9
16
-
0
7-
2021
530
n
m
The wavelength(s) of light the
instrument uses are shown
in nanometres (nm).
While some Lumiso instruments
use more than one wavelength,
the Chlorine, Chlorine Dioxide
and Ozone instruments all use
only this wavelength.
If nothing is shown here, it is
because Lumiso has not been
“blanked” on the wavelength
highlighted.
1
2
Check Standard Mode is
accessed from the Settings
Menu
Scroll to the Check Standard
icon and confirm
icon and confirm
17

palintest Lumiso Chlorine Specifications

General

Instrument	Single wavelength, direct-reading colorimeter
Optics	LED light source optical system with narrow band wavelength filters and photodetectors
Test Cells	25 mm diameter tubes
Wavelengths	Automatic wavelength selection of 530 nm
Wavelength Tolerance	± 2 nm
Filter Bandwidth	5 nm
Blank/Zero setting	Held in memory, but instrument will prompt for re-blanking after 50 minutes
LCD Display	226 x 138 pixel with adjustable backlight
Results Log	50 results, with date, time and label
Operating Conditions	0 – 50°C 90% Relative Humidity (non-condensing)
Waterproof Rating	IP67 (Waterproof)
Power Supply	3 x 1.5V AA batteries USB Port 6V max, 200mA max (DC)
USB Port	Micro USB Type B

Weight and Dimensions

Size	163 x 70 x 45 mm
Weight	275g (including batteries)
