palintest Lumiso Chlorine User Manual

10
Ensure that your Lumiso
Instrument is clean and dry.
Place tubes in the
instrument with white
diamond aligned to the
mark on the instrument.
6
During sample testing
or blanking, remove any
attached bubbles by
capping the tube and
rotating as shown.
4
Ensure tubes are dry on
the outside before placing
them in the instrument.
5
28

palintest Lumiso Chlorine Specifications

General

Instrument	Single wavelength, direct-reading colorimeter
Optics	LED light source optical system with narrow band wavelength filters and photodetectors
Test Cells	25 mm diameter tubes
Wavelengths	Automatic wavelength selection of 530 nm
Wavelength Tolerance	± 2 nm
Filter Bandwidth	5 nm
Blank/Zero setting	Held in memory, but instrument will prompt for re-blanking after 50 minutes
LCD Display	226 x 138 pixel with adjustable backlight
Results Log	50 results, with date, time and label
Operating Conditions	0 – 50°C 90% Relative Humidity (non-condensing)
Waterproof Rating	IP67 (Waterproof)
Power Supply	3 x 1.5V AA batteries USB Port 6V max, 200mA max (DC)
USB Port	Micro USB Type B

Weight and Dimensions

Size	163 x 70 x 45 mm
Weight	275g (including batteries)
