palintest Lumiso Chlorine User Manual

Wait 2 minutes.
Alternatively, to use the
automatic timer, immediately
place tube in the cell holder and
press back then select
TCl
2
(0-5), then press read
Remove any bubbles by holding
the tube and rotating as shown.
Take the Photometer reading.
Result = Total Chlorine
NB: Combined Chlorine =
Total Chlorine – Free Chlorine
Lumiso
Pooltest
A Palintest Product
Lumiso
A Palintest Product
12
:
28
:4
9
1
6
-
0
7-2
0
21
T
Cl

(
0-5
)
2
.5
5
mg
/
L
15
14
16
38
press back then select
Cap the tube.
13

palintest Lumiso Chlorine Specifications

General

Instrument	Single wavelength, direct-reading colorimeter
Optics	LED light source optical system with narrow band wavelength filters and photodetectors
Test Cells	25 mm diameter tubes
Wavelengths	Automatic wavelength selection of 530 nm
Wavelength Tolerance	± 2 nm
Filter Bandwidth	5 nm
Blank/Zero setting	Held in memory, but instrument will prompt for re-blanking after 50 minutes
LCD Display	226 x 138 pixel with adjustable backlight
Results Log	50 results, with date, time and label
Operating Conditions	0 – 50°C 90% Relative Humidity (non-condensing)
Waterproof Rating	IP67 (Waterproof)
Power Supply	3 x 1.5V AA batteries USB Port 6V max, 200mA max (DC)
USB Port	Micro USB Type B

Weight and Dimensions

Size	163 x 70 x 45 mm
Weight	275g (including batteries)
