Chapter 1 Overview — What you can do with this unit
- 14 -
What you can do with this unit
Recording to the memory card
Recording in following types is possible.
≥ (For the )
P2 recording (P2 MXF compatible)
≥ MOV recording (UHD and FHD recording)
≥ MP4 recording (UHD and FHD recording)
≥ AVCHD recording
≥ Simultaneous recording
≥ Relay recording
≥ Interval recording
≥ Background recording
≥ Pre-recording
Linking to external devices
Connecting to TV/monitor
Connect to a TV/monitor and output images.
≥ When using / , use a BNC cable (<SDI OUT> terminal) to connect a TV/monitor.
≥ Use a commercially-available High Speed HDMI cable. If possible, we recommend using a cable with a length of 3 m or less.
≥ (For the /)
Use a commercially-available 5C-FB or equivalent double-shielded cable for the BNC cable.
Card reader mode
Data (files) for performing nonlinear editing on a computer are transferred.
≥ The unit supports USB2.0.
*1 Memory cards are optionally available. They are not supplied with the unit.
*2 A USB2.0 cable is not supplied with the unit.
Use a commercially-available generic USB cable conforming to USB2.0. If possible, we recommend using a cable with a length of 1.5 m or less.
The unit does not offer a bus-powered function.
A HDMI cable
B (For the /)
BNC cable (<SDI OUT> terminal)
C TV/Monitor
When using a DVI converter, etc., to connect an HDMI cable to this unit, make sure that you connect last to the <HDMI> terminal on this unit.
Connecting first to the <HDMI> terminal on this unit may cause a malfunction.
A Memory card
*1
B USB2.0 cable
*2
C Computer
