Chapter 7 Output and Screen Display — Screen status display
- 166 -
Mode check display
The unit’s settings and status can be displayed on the viewfinder or LCD monitor screen for check.
Press the <DISP/MODE CHK> button for 1 second or more while displaying the camera image screen to display the STATUS screen of the mode check.
Each time you press the <DISP/MODE CHK> button, the display switches in the order STATUS screen, FUNCTION screen, AUDIO screen, SWITCH
screen, NETWORK screen, camera image screen.
Each screen of the mode check is displayed for approximately 5 seconds.
The screen does not switch while the <DISP/MODE CHK> button is pressed.
Press the <EXIT> button while each screen is displayed to return to the camera image screen.
0 The mode check screen cannot be displayed even when you press the <DISP/MODE CHK> button in the following case:
j When the [VIDEO OUT/LCD/VF] menu → [LCD] → [SELF SHOOT] → [MIRROR] is set and the LCD monitor is rotated toward the lens (when mirror
shooting)
FUNCTION screen
Displays the video output settings and information of the recording media.
*1 Displayed when using / .
*2 Available for setting when using .
40
Area mode function, face detection/tracking
AE&AF function
l — l —
41 Waveform monitor ll——
42 IR recording l — l —
43 Digital zoom l — l —
44 Focus l — l —
45 Audio monitor volume adjustment llll
Item Description
[SDI OUT]
*1
[VIDEO OUT FORMAT] Displays with [1920×1080p]/[1920×1080i]/[1920×1080PsF]/[1280×720p] the
signals output through the <SDI OUT> terminal.
[VIDEO OUT CHAR] Displays with [ON]/[OFF] whether the characters output through the <SDI OUT>
terminal are superimposed.
[HDMI OUT] [VIDEO OUT FORMAT] Displays with [3840×2160p]/[3840×2160p(420/8bit)]/[1920×1080p]/
[1920×1080i]/[1280×720p]/[720×480p]/[720×576p] the signals output through
the <HDMI> terminal.
[VIDEO OUT CHAR] Displays with [ON]/[OFF] whether the characters output through the <HDMI>
terminal are superimposed.
[CARD STATUS] — Displays the status, remaining recording capacity, and the total capacity of the
memory card inserted in the card slot.
It is not displayed when set to the [NETWORK] menu → [NETWORK FUNC] →
[NDI|HX]
*2
.
The status of the memory card that is displayed are following types.
≥ [NO CARD]: Memory card is not inserted.
≥ [UNSUPPORTED]: Memory card is not supported.
≥ [FORMAT ERROR]: Memory card cannot be used. (Format error)
≥ [PROTECTED]: It is write protected. (The write-protection switch of the
memory card is set to the LOCK side)
≥ [NO REMAIN]: There is no remaining recording capacity.
≥ [NOT SDXC]: SDXC memory card is not inserted in the MOV recording/MP4
recording.
≥ Cases other than above: The remaining recording capacity is displayed in 0%
through 100%.
[TOTAL] Displays the remaining recording capacity/total capacity of the memory cards in
the card slot 1 and the card slot 2.
[SLOT1] Displays the status and remaining recording capacity/total capacity of the
memory card in card slot 1.
[SLOT2] Displays the status and remaining recording capacity/total capacity of the
memory card in card slot 2.
No Item
Camera image
screen
When the <DISP/
MODE CHK> button
is pressed
STATUS Playback screen
CX10
CX10
