Description of parts
For details, refer to the respective pages.
Camera-recorder
Viewfinder (P9, P13,
P15, P25-P27, P34,
P78)
Eye-cup (P15)
Diopter adjustment lever (P25)
Battery release button
(P23)
START/STOP button
(P13, P34)
Battery connector
DC input (INPUT 7.9 V) socket
(P11, P14)
Shoulder strap eyelet (P16)
PHONES jack (P47,
P49, P54, P65, P79)
DV connector (P41, P54,
P60-P62, P75-P78)
CAM REMOTE jack
(2.5 mm diameter)
Tripod mounting hole
(P9)
Shoe (P15, P56)
Zoom buttons (P35, P75)
POWER lever (P12-P14,
P23, P34, P48, P57, P79)
Hand strap
(P15)
Shoulder strap eyelet
(P16)
Cassette holder
(P12, P14, P83)
Cassette cover
(P12, P14, P34)
USER button (P40, P51,
P57, P62, P63, P74)
POWER lamp (P12,
P14, P23, P48)
Built-in stereo microphone
(P37, P57, P58, P63, P75,
P77, P79)
START/STOP button
(P35, P75)
OPEN/EJECT lever
(P12, P14)
