41
CN# in the
Instructions
VF HR12-14RA-20SC (Hirose)
Pin# Signal
1 VF+1
2V
2 VF+1
2V
3 UNREG_GND
4 VF-PBOUT_GND
5 VF-PBOUT_GND
6 VF-YOUT
7 VF-YOUT_GND
8 VF_CLK
9 VF_WR
10 VF_DATA
11 UNREG_GND
1
2 ZEBRA_SW
1
3 PEAKING
14 TA_BOX_ACT
15 VF-PROUT
16 VF-PBOUT
17 VF_SW
3
18 FRONT_VR
19 TA_TALLY
2
0
F_GND
REAR VF CN D02-29S-N-F0 (JAE)
Pin# Signal
1 VF-YOUT
2 VF-PBOUT
3 VF-PROUT
4
5 I
2C_DATA
6 R_TALLY
7 TA_TALLY
8
9 LCD+1
2V
10 1
2V
11 VF-YOUT_GND
1
2 VF-PBOUT_GND
1
3 VF-PROUT_GND
14 AGND
15 DGND
16
17 UNREG_GND
18
19 F_GND
2
0 LCD_ACT
2
1
22
23 PEAKING_CONT
2
4 I2C_CLK
25
G_TALLY
2
6 VF_P_REQ
2
7
28
29
Buildup unit I/F QR/P8-20S-C(01) (Hirose)
Pin# Signal
1 VF_Y
OUT3
2 VF_Y
OUT3_GND
3 VF_PBOUT
3
4 VF_PBOUT
3_GND
5 VF_PR
OUT3
6 VF_PR
OUT3_GND
7 BU_CRN_DATA_H
8 BU_CRN_DATA_C
9 BU_CRN_CONT_H
10 BU_CRN_CONT_C
11 OPT_AC(H)
1
2 LNS_ID_CO
1
3 LNS_IP–B
14 I
2C_DATA
15 I
2C_CLK
16 LNS_FOCUS_POS
17 LNS_L_TXD
18 BU_ACT
19 DGND
2
0 OPT_AC(C)
TALLY OUT HR10A-7R-4SC (Hirose)
Pin# Signal
1 UNREG_GND
2 R_TALLY_OUT (contact output)
3 G_TALLY_OUT (contact output)
4 SCRIPT+1
2V
CN# in the
Instructions
DC IN HA16RA-4P (Hirose)
Pin# Signal
1 EXT_GND
2
3
4 EXT+1
2V
MIC1 HA16PRM-3SB(05) (Hirose)
Pin# Signal
1 MIC1_GND
2 MIC1(H)
3 MIC1(C)
MIC2 HA16PRM-3SB(05) (Hirose)
Pin# Signal
1 MIC
2_GND
2 MIC
2(H)
3 MIC
2(C)
DC OUT HR10A-7R-4SC (Hirose)
Pin# Signal
1 UNREG_GND
2 R_TALLY_OUT (contact output)
3 G_TALLY_OUT (contact output)
4 SCRIPT+1
2V
EARPHONE HSJ0927-0160209 (Hoshiden)
Pin# Signal
1 PHONE_GND
2 PHONE_OUT
3
TRUNK HR10A-10R-12SC (Hirose)
Pin# Signal
1 CMD-OUT0(H)
2 CMD-OUT0(C)
3 CMD-IN0(H)
4 CMD-IN0(C)
5 CMD-OUT1(H)
6 CMD-OUT1(C)
7 CMD-IN(H)
8 CMD-IN1(C)
9
10 DGND
11
1
2
LENS HR10A-10R-12SC (Hirose)
Pin# Signal
1 LENS_RETSW
2 LENS_VTRSW
3 AGND
4 ENF_SERVO
5 IRIS_CONT
6 LENS+1
2V
7 IRIS_POSI
8 H_IRIS_A-R
9 EXTENDER
10 ZOOM_POSI
11 FOCUS_POS/L_RXD
1
2
S_IRIS_A-R/L_TXD
FRONT MIC HA16PRM-3S(05) (Hirose)
Pin# Signal
1 FRONT_MIC_GND
2 FRONT_MIC(H)
3 FRONT_MIC(C)
AK-HC3500 connector pin assignment
CN# in the
Instructions
K OPT FIBRE
AK-HC3500E: OPS2402-R (Tajimi)
AK-HC3500ES: ED
W.3K.93C.TLC (LEMO)
Pin# Signal
01 OPT-TX (Mark Band = IN)
0
2 OPT-RX (Mark Band = OUT)
1 STBYINCOM-R
2 STBYINCOM-T
3 A
C220V(C)
4 A
C220V(H)
INCOM XLR5-31F77 Female (ITT Cannon)
Pin# Signal
1 TALK_GND
2 TALK
3 RECEIVE_GND
4 RECEIVE
5 PGM
RET CONT HR10A-7R-6SC (Hirose)
Pin# Signal
1 INCOM1_MIC_ON
2 INCOM
2_MIC_ON
3 AGND
4 RET_CNT
3
5 RET_CNT1
6 RET_CNT
2
EXT I/O HR10A-13R-20SC (Hirose)
Pin# Signal
1 BU_CRN_DATA_H
2 BU_CRN_DATA_C
3 BU_CRN_CONT_H
4 BU_CRN_CONT_C
5 DGND
6 CRN_INC_R
7 CRN_INC_R_GND
8 CRN_INC_T
9 CRN_INC_T_GND
10 CRN_PGM1_LVL
11 CRN_PGM
2_LVL
12
13
14 G_TALLY_VF
15 R_TALLY_VF
16 T_TALLY_VF
17 CRANE_ACT
18 EXT+1
2V
19
2
0 UNREG_GND
HD SDI BNC(75)J-H.FLJ-BPA(40) (Hirose)
Pin# Signal
1 SDI_OUT
2 SDI_OUT_GND
AUX BNC(75)J-PL72J-BPA (Hirose)
Pin# Signal
1 AUX
2 AUX_GND
PROMPT/GL BCJ-R/1 (Canare)
Pin# Signal
1 PROMPT/GL_IN
2 PROMPT_GND/GL_IN_GND
REMOTE HR10A-10R-10SC (Hirose)
Pin# Signal
1 CAM_DATA(H)
2 CAM_DATA(C)
3 CAM_CONT(H)
4 CAM_CONT(C)
5
6
7
8
9 RCOP+1
2V
10 UNREG_GND
