Serial Port
Connecting Serial device
Keyboard Base
1. Slide the cover to the arrow direction.
The cover isunlocked.
2. Open the cover.
3. Connect the serial device to the serial port (A).
4. Connect the serial device to the connector of the serial cable.
Tablet
<Only for model with Serial Port>
1. Slide the cover to the arrow direction.
The cover isunlocked.
2. Open the cover.
3. Connect the serial device to the serial port (A).
4. Connect the serial device to the connector of the serial cable.
N O T E
n When connecting a cable, be sure to secure it with screws.
n It does not support serial mouse.
