1. Remove (D) from the strap joint and next remove (E).
2. Move (E) and adjust the position (F).
3. Attach (E), then (D) to the joint.
Attach the hand strap firmly so that the strap does not come off.
When Inserting/Removing the Battery Pack
C A U T I O N
n Place the computer on a soft cloth with the panel side down. In addition, make sure that there is no item under the tablet.
1. Remove the Velcro straps part of the hand strap.
2. Raise the upper side of the hand strap.
With the upper side of the hand strap lifted up, remove the backcover.
Refer to the "Replacing the Battery Pack".
To Next Page
