Panasonic CF-D1 Series

34
Appendix
Specications
Thispageprovidesthespecicationsforthebasicmodel.Themodelnumberisdifferentaccordingtotheunitcongu-
ration.
l To check the model number:
Check the bottom of the computer or the box the computer came in at the time of purchase.
l To check CPU speed, memory size and the hard disk drive (HDD) size:
Run the Setup Utility (è Reference Manual “Setup Utility”) and select [Information] menu.
[Processor Speed]: CPU speed, [Memory Size]: Memory size, [Hard Disk]: Hard disk drive size
n Main Specications
Model No. CF-D1A Series
CPU Intel
®
Core™ i5-2520M
(2.5 GHz, Intel
®
Smart Cache 3 MB
*1
)
Chip Set Intel
®
6 Series Express Chipsets QM67
Video controller Built-in Chip Set
Main Memory
*2
4 GB
*1
, DDR3 SDRAM (8 GB
*1
Max.)
Video Memory
UMA (<32-bit> 1429 MB
*1
Max., <64-bit> 1696 MB
*1
Max.)
*3
UMA (1024 MB
*1
Max.)
*3
Hard Disk Drive 320 GB
*4
(Serial ATA)
Approx. 40 GB
*4
is used as a partition with recovery tools. (Users cannot use this partition.)
Display Method 13.3 type with Touchscreen (TFT) (1366 × 768 dots) (16:9)
Internal LCD 65,536/16,777,216 colors
(800 × 600 dots / 1024 × 768 dots / 1280 × 600 dots / 1280 × 720 dots / 1280 × 768 dots /
1360 × 768 dots / 1366 × 768 dots)
*5
External Display
*6
65,536 / 16,777,216 colors (800 × 600 dots / 1024 × 768 dots / 1280 × 768 dots /
1366 × 768 dots / 1600 × 1200 dots / 1920 × 1080 dots / 1920 × 1200 dots)
Touchscreen Resistive
Circular Polarizer
Wireless LAN
Intel
®
Centrino
®
Advanced - N 6205 (è page 35)
Bluetooth
*7
è page 35
Wireless WAN
*8
Ericsson F5521gw (è page 36)
LAN IEEE 802.3 10Base-T / IEEE 802.3u 100BASE-TX / IEEE 802.3ab 1000BASE-T
(2nd LAN
*9
: IEEE 802.3 10BASE-T, IEEE 802.3u 100BASE-TX)
Sound WAVE and MIDI playback, Intel
®
HighDenitionAudiosubsystemsupport
Security Chip TPM (TCG V1.2 compliant)
*10
Card
Slots
PC Card Slot
*11
× 1, Type I or Type II, Allowable current 3.3 V: 400 mA, 5 V: 400 mA
ExpressCard Slot × 1, ExpressCard/34 or ExpressCard/54
SD Memory Card Slot
*12
× 1
Contact Smart Card Slot
*13
× 1
SIM Card Slot
*8
× 1
RAM Module Slot × 2, DDR3 SDRAM, 204-pin, 1.5 V, SO-DIMM, PC3-10600 Compliant
Interface USB2.0 Ports × 3 or × 4
*14
/ Serial Port (Dsub 9-pin male)
*15
/ LAN Port (RJ-45) × 1 or × 2
*9
/
VGA Port (Mini DSub 15-pin female)
*16
/ Microphone Jack (Miniature jack, 3.5 DIA) / Head-
phone Jack (Miniature jack, 3.5 DIA, Impedance 32 W, Output Power 4 mW × 2, Stereo) /
Expansion Bus Connector (Dedicated 100-pin female) / Rugged USB2.0 Port
*17
Pointing Device Touchscreen
Button Security, Application × 3, Function
Fingerprint Reader
*18
Array Size : 192 × 4 pixels, Image Size : 192 × 512 pixels, Image Resolution : 508 DPI
Front Camera
*19
Specicationsdifferdependingonthemodel.
Rear Camera
*20
Specicationsdifferdependingonthemodel.
Power Supply AC adaptor or Battery pack
AC Adaptor
*21
Input: 100 V to 240 V AC, 50 Hz/60 Hz, Output: 15.6 V DC, 7.05 A
