1 ABOUT LEAD FREE
SOLDER (PbF)
Distinction of PbF PCB:
PCBs (manufactured) using lead free solder will have a PbF
stamp on the PCB.
Caution :
•
• •
• Pb free solder has a higher melting point than standard
solder; Typically the melting point is 50 - 70°F (30 -
40°C) higher. Please use a soldering iron with
temperature control and adjust it to 700 ± 20°F (370 ±
10°C). In case of using high temperature soldering iron,
please be careful not to heat too long.
•
• •
• Pb free solder will tend to splash when heated too high
(about 1100°F/600°C)
•
• •
• This lead free solder will be used for the products after
serial No. 1,000,001.
2 FEATUERS
•
• •
• 18-FM, 6-AM presets with preset scan
•
• •
• Digital servo for reliable CD playback.
•
• •
• Removable face plate.
11 PACKAGE AND IC BLOCK DIAGRAM 8
12 REPLACEMENT PARTS LIST
12
13 EXPLODED VIEW (Unit)
16
14 CD PLAYER MECHANICAL PARTS LIST
17
15 EXPLODED VIEW (CD Deck)
18
16 WIRING DIAGRAM
19
17 SCHEMATIC DIAGRAM-1
23
18 SCHEMATIC DIAGRAM-2
25
19 SCHEMATIC DIAGRAM for printing with A4 size
27
3 LASER PRODUCTS
4 REPLACEING THE FUSE
Use fuses of the same specified rating (15A). Using different
substitutes or fuses with higher ratings, or connecting the
product directly without a fuse, could cause fire or damage to
the stereo unit.
