Operation Details
Soft Dry Operation Time Diagram
<Description of operation>
a – c, p~r : Cooling Operation
c – p, r~v : Soft Dry Operation
e – f : Soft Dry OFF
j – l : 60 sec. Forced Operation
q – t : Anti Freezing Control
Operation
Stop
a
b
c
def
g
h
i
j
k
l
m
n
opq
rs
tuv
Basic Time
Compressor
Indoor Fan
Outdoor Fan
Operation LED
4 Way Valve
2 Way Valve (A241K)
1’1’ 1’
1’6’
6’
6’ 6’
4’
1’
Cooling ON
Cooling OFF
Soft Dry OFF, ON
1.5°C
1.0°C
SLoSLo SLo SLoSLo SLo SLo SLoSLo SLo SLo SLo
6’
Intake Air
Temperature
Set Temp.
Indoor
Heat
Exchanger
Temp.
10°C
2°C
