– 50 –
MAC9512086C2
CS-A73KE
<Model: CS-A73KE / CS-A93KE / CS-A123KE>
Replacement Parts List
NO. DESCRIPTION & NAME Q’TY CS-A73KE CS-A93KE CS-A123KE REMARKS
1 CHASSY COMPLETE 1 CWD50C338
@@
2 PARTICULAR PIECE 1 CWD931019
@@
3 FAN MOTOR 1 CWA92288 CWA92286 CWA92290 _
4 LEAD WIRE – FAN MOTOR 1 CWA67C2097
@@
5 CROSS FLOW FAN 1 CWH02C060
@@
6 BEARING 1 CWH64K007
@@
7 SCREW – CROSS FLOW FAN 1 CWH4580304
@@
8 EVAPORATOR & TUBE ASS’Y COMPLETE 1 CWB30C259
@
CWB30C260
9 INTAKE AIR SENSOR HOLDER 1 CWH32142
@@
10 ANTI VIBRATION BUSHING 1 CWH50211
@@
11 FLARE NUT (1/4”) 1 CWH6002140
@@
12 FLARE NUT (1/2”) OR (3/8”) 1 CWT25005 (3/8”)
@
CWT25007 (1/2”)
13 DISCHARGE GRILLE COMPLETE 1 CWE20C610 CWE20C624
@
14 VERTICAL VANE WITH TAB 2 CWE24458
@@
15 VERTICAL VANE 10 CWE24457
@@
16 CONNECTING BAR 2 CWE26194
@@
17 AIR SWING MOTOR 1 CWA98260 CWA98C033
@
_
18 LEAD WIRE – AIR SWING MOTOR 1 CWA67C2106
@@
19 CAP FOR DRAIN TRAY 1 CWH52C003
@@
20 HORIZONTAL VANE 1 CWE24462
@@
21 CONTROL BOARD 1 CWH10965
@@
22 POWER SUPPLY CORD 1 CWA20C751
@@
23 SLIDE SWITCH 1 CWA04088
@@
_
24 ELECTRONIC CONTROLLER 1 CWA741388 CWA741491
@
_
25 RECEIVER 1 CWA74919
@@
_
26 INDICATOR COMPLETE 1 CWA741376`
@@
_
27 LEAD WIRE – INDICATOR 1 CWA67C2105
@@
28 TERMINAL BOARD 1 CWA28C575
@
CWA28C576 _
29 INDICATOR HOLDER 1 CWD931018
@@
30 SENSOR COMPLETE 1 CWA50C608
@@
_
31 CONTROL BOARD FRONT COVER 1 CWH13456
@@
32 CONTROL BOARD TOP COVER 1 CWH13457
@@
33 REMOTE CONTROL COMPLETE 1 CWA75C723
@@
_
34 REMOTE CONTROL HOLDER* 1 CWH36161
@@
35 FRONT GRILLE COMPLETE 1 CWE11C978
@@
36 INTAKE GRILLE COMPLETE 1 CWE22C333
@@
37 DECORATION BASE COMPLETE 1 CWE35C023
@@
38 TAB 2 CWD931020
@@
39 AIR FILTER 2 CWD00240
@@
40 GRILLE DOOR 1 CWE14236
@@
41 SCREW FOR FRONT GRILLE 2 XTN4+16C
@@
42 CAP FOR FRONT GRILLE 2 CWH52267
@@
43 DRAIN HOSE 1 CWH5880580
@@
44 OPERATING INSTRUCTIONS 1 CWF561595
@@
(ENG/SPA/GER/FRA/NED/ITA)
44a OPERATING INSTRUCTIONS (POR/GRK) 1 CWF56195A
@@
44b OPERATING INSTRUCTIONS (RUSSIAN) 1 CWF56195B
@@
45 INSTALLATION INSTRUCTIONS 1 CWF61674
@
CWF61685
46 INSTALLATION PLATE 1 CWH36157
@@
47 BAG COMPLETE - INSTALLATION SCREW 1 CWH82C144
@@
48 AIR PURIFYING FILTER COMPLETE 1 CWD00C111
@@
49 AIR PURIFYING FILTER 2 CWD00220
@@
_
(Note) ● All parts are supplied from MACC, Malaysia (Vendor Code: 086).
● _ marked parts are recommended to be kept in stock.
● * Is an optional parts
Untitled-15 6/19/00, 11:24 AM50
