MAC9512086C2
CS-A73KE
Product Specifications
Cooling Capacity
Heating Capacity
Moisture Removal
Power Source
Airflow Method
Air Volume
Noise Level
Electrical
Data
Piping Connection Port
(Flare piping)
Pipe Size
(Flare piping)
Drain
Hose
Power Cord Length
Number of core-wire
Dimensions
Net Weight
Compressor
Air Circulation
Inner diameter
Length
Input
Running Current
COP
Starting Current
Height
Width
Depth
Type
Motor Type
Rated Output
Type
Material
Motor Type
Input
Rated Output
Fan Low
Speed Medium
High
Indoor Air (Lo)
Indoor Air (Me)
Indoor Air (Hi)
Outdoor Air
Unit
kW
Btu/h
kW
Btu/h
s/h
Pint/h
Phase
V
Cycle
OUTLET
INTAKE
m
3
/min (cfm)
m
3
/min (cfm)
m
3
/min (cfm)
m
3
/min (cfm)
dB (A)
W
A
W/W
A
inch
inch
inch
inch
mm
m
m
inch (mm)
inch (mm)
inch (mm)
lb (kg)
W
W
W
rpm
rpm
rpm
2.20 - 2.10
7,500 - 7,200
2.45 - 2.40
8,360 - 8,200
1.4
3.0
Single
230 - 220
50
Cooling ; 700 - 680
Heating ; 640 - 600
Cooling ; 3.6 - 3.5
Heating ; 3.4 - 3.2
Cooling ; 3.14 - 3.09
Heating ; 3.83 - 4.00
15.5
CU-A73KE
TOP VIEW
–
–
–
27.8 (981) - 26.8 (946)
Cooling ; High 47/45
Heating ; High 49/47
G ; 3-way valve 3/8"
L ; 2-way valve 1/4"
G (gas side) ; 3/8"
L (liquid side) ; 1/4"
–
–
–
–
18-29/32 (480)
30-23/32 (780)
9-21/32 (245)
64 (29.0)
Rotary (1 cylinder)
rolling piston type
Induction (2-pole)
600
Propeller Fan
AES + Glass Fiber 12%
Induction (6-pole)
65.8 - 57.5
20
–
–
730 - 705
CS-A73KE
SIDE VIEW
Cooling ; 5.9 (206) - 5.7 (200)
Heating ; 6.7 (238) - 6.6 (233)
Cooling ; 6.7 (237) - 6.4 (227)
Heating ; 7.6 (269) - 7.5 (265)
Cooling ; 7.5 (260) - 7.2 (250)
Heating ; 8.5 (300) - 8.4 (300)
–
Cooling ; High 34/33, Low 29/27
Heating ; High 36/35, Low 30/28
G ; Half Union 3/8"
L ; Half Union 1/4"
G (gas side) ; 3/8"
L (liquid side) ; 1/4"
12
0.7
2.0
3 (1.0 mm
2
)
10-31/32 (279)
31-15/32 (799)
7-15/32 (190)
20 (9.0)
–
–
–
Cross-flow Fan
AS + Glass Fiber 30%
Induction (4-pole)
29.0 - 27.0
10
835 - 810
945 - 920
1055 - 1030
