– 30 –
MAC9509078C2
CS-A73KE
Operation Details
12) Powerful Mode Operation
Purpose of this operation is to be obtain the setting temperature quickly.
a) Cooling and Soft Dry Mode
• When the Powerful Mode is set, the set temperature will be automatically decreased 3°C against the
present setting temperature. This operation automatically will be running under Super High Fan Speed.
• Vertical Airflow Direction :–
In "manual" setting, the vane will automatically shift down 10° lower than previous setting.
In "Auto" setting, the vane will automatically swing up and down. However the upper and lower limit will
be shifted 10° downward.
b) Heating Mode
• When the Powerful Mode is set, the set temperature will be automatically increased 3°C against the present
setting temperature.
• The Fan Speed will shift as shown below:
• When the Auto Fan speed is selected, the fan speed will automatically
change from SLo to Me depending to the Indoor piping temperature.
• When the manual Fan Speed is selected, the fan speed will automati-
cally change from SLo to Lo
–
, then follows set fan speed when the
Indoor piping temperature reaches 42°C.
• * shows different temperature than normal heating. This higher
temperature is to provide warmer air.
• Vertical Airflow Direction:–
In "manual" setting, the vane will automatically shift down 5° lower than previous setting.
In "Auto" setting, the vane will automatically shift between upper and lower limit depending on the intake
air temperature as Heating Mode, Airflow Direction Auto-Control. However the upper and lower limit will
be shifted 5° downward.
c) Powerful mode will operate for 15 minutes only.
d) Powerful Mode will stop if:–
• Power mode button is pressed again.
• Stopped by ON/OFF switch.
• Timer-off activates.
• Economy mode button is pressed.
• Sleep mode button is presssed.
• Operating mode is changed.
*48
* 42
34
30
38
30
28
15
Lo
-
SLo
OFF
Indoor
piping temp °C
Me
Lo
Set Fan Speed
Untitled-11 6/19/00, 11:11 AM30
