– 29 –
CS-A73KE
MAC9509078C2
Operation Details
11) Economy Mode Operation
Purpose of this operation is to save or reduced electrical power consumption of the room air conditioner.
However consumer is advised to use Economy Mode operation after the room temperature reaches the desired
temperature.
a) Cooling and Soft Dry Mode
• When the Economy Mode is set, the set temperature will be automatically increased 0.5°C against the
present setting temperature. This operation automatically will be running under Random Low Fan Speed.
• Vertical Airflow Direction :–
In "manual" or "Auto" setting, the vane will automatically change to Auto Air Swing.
b) Heating Mode
• When the Economy Mode is set, the temperature will be automatically decreased 0.5°C against the present
setting temperature.
• The Fan Speed will shift as shown below:
• When the Auto Fan speed is selected, the fan speed will automatically
change from Slo to Me depending to the Indoor piping temperature.
• When the manual Fan Speed is selected, the fan speed will automati-
cally change from SLo to Lo
–
, then follows set fan speed when the
Indoor piping temperature reaches 39°C
• Vertical Airflow Direction:–
In "manual" or "Auto" setting, the vane will automatically change to Auto Air Swing.
c) Economy Mode will stop if:–
• Economy mode button is pressed again.
• Stopped by ON/OFF switch.
• Timer-off activates.
• Powerful mode button is pressed.
• Fan Speed control button is pressed.
• Sleep mode button is pressed ON
• Operating mode is changed.
Set Fan Speed
45
39
34
30
38
30
28
15
Lo
-
SLo
OFF
Indoor
piping temp °C
Me
Lo
