– 54 –
MAC9512086C2
CS-A73KE
<Model: CU-A123KE>
Replacement Parts List
NO. DESCRIPTION & NAME Q’TY CU-A123KE REMARKS
1 CHASSY ASS’Y 1 CWD50K659A
2 FAN MOTOR BRACKET 1 CWD54254
3 SCREW – FAN MOTOR BRACKET 6 CWH55413
4 FAN MOTOR 1 CWA95381 _
5 SCREW – FAN MOTOR MOUNT 4 CWH55252
6 COMPRESSOR 1 2KS224D5CA02 _
7 ANTI – VIBRATION BUSHING 3 CWH50055
8 NUT – COMPRESSOR MOUNT 3 CWH4582065
9 CONDENSER 1 CWB32C336
10 4-WAY VALVE 1 CWB00003 _
11 TUBE ASS'Y (CHECK VALVE / CAPILLARY) 1 CWT01C652
12 HOLDER COUPLING ASS’Y 1 CWH35K063
13 3-WAY VALVE 1 CWB01480 _
14 2-WAY VALVE 1 CWB02308 _
15 STRAINER 1 CWB11025
16 V – COIL COMPLETE 1 CWA43C689 _
17 SOUND PROOF BOARD 1 CWH15288
18 SOUND PROOF MATERIAL 1 CWG30911
19 WIRE NET 1 CWD04197A
20 AIR GUIDER PROPELLER FAN 1 CWD31138
21 OVERLOAD PROTECTOR 1 CWA12360 _
22 HOLDER – O.L.P. 1 CWH7041200
23 TERMINAL COVER 1 CWH17006
24 NUT – TERMINAL COVER 1 CWH7080300
25 TEMPERATURE RELAY 1 CWA14C000 _
26 CONTROL BOARD 1 CWH10972
27 TERMINAL BOARD ASS’Y 1 CWA28C583
28 ELECTROLYTIC CAPACITOR 1 CWA32C045 _
29 TERMINAL BOARD ASS’Y 1 CWA4711012
30 CAPACITOR-COMPRESSOR 1 CWA31647 _
(30µF, 370 V)
31 HOLDER CAPACITOR 1 CWH30057
32 CAPACITOR – FAN MOTOR 1 CWA31227 _
(1.5µF, 400 V)
33 ELECTROMAGNETIC SWITCH 2 CWA00059 _
34 ELECTROLYTIC CAPACITOR 1 CWA32C067 _
35 PROPELLER FAN ASS’Y 1 CWH00K087
36 NUT-PROPELLER FAN 1 CWH56053
37 CABINET SIDE PLATE (RIGHT) 1 CWE04217A
38 CABINET SIDE PLATE (LEFT) 1 CWE04220A
39 CABINET FRONT PLATE 1 CWE06K104A
40 HANDLE 1 CWE16037C
41 CONTROL BOARD COVER 1 CWH13461
42 PLATE FOR CONTROL BOARD COVER 1 CWD91258
43 CABINET TOP PLATE 1 CWE03K035A
(Note) ● All parts are supplied from MACC, Malaysia (Vendor Code: 086).
● _ marked parts are recommended to be kept in stock.
