123
REF.
NO.
PART NAME & DESCRIPTION QTY CS-A9MKD CS-A12MKD REMARK
1 CHASSIS COMPLETE 1 CWD50C1599 ←
2 FAN MOTOR 1 CWA921434 ← O
3 CROSS FLOW FAN COMPLETE 1 CWH02C1076 ←
4 BEARING ASS’Y 1 CWH64K007 ←
5 SCREW - CROSS FLOW FAN 1 CWH551146 ←
6 GENERATOR COMPLETE 1 CWH94C0028 ←
7 EVAPORATOR 1 CWB30C3154 CWB30C3360
8 FLARE NUT (LIQUID) 1 CWT251026 ←
9 FLARE NUT (GAS) 1 CWT251061 CWT251062
10 HOLDER SENSOR 1 CWH32143 ←
11 E-ION AIR PURIFYING SYSTEM 1 CWD93C1090 ←
12 BACK COVER CHASSIS 1 CWD933233 ←
13 CONTROL BOARD CASING 1 CWH102370 ←
14 TERMINAL BOARD COMPLETE 1 CWA28C2426 CWA28C2428 O
15 ELECTRONIC CONTROLLER - MAIN 1 CWA73C5185 CWA73C5183 O
17 ELECTRONIC CONTROLLER - HVU 1 CWA745348 ← O
18 ELECTRONIC CONTROLLER - INDICATOR 1 CWA746280 ← O
19 ELECTRONIC CONTROLLER - RECEIVER 1 CWA745288 ← O
20 INDICATOR HOLDER 1 CWD933021 ← O
21 SENSOR COMPLETE 1 CWA50C2401 ←
22 SENSOR COMPLETE (ECO) 1 CWA50C2758 ←
23
ELECTRONIC CONTROLLER (ECO SENSOR -
L)
1 CWA745791 ←
23a
ELECTRONIC CONTROLLER (ECO SENSOR -
R)
1 CWA746206 ←
24 ELECTRONIC CONTROLLER (COMPARATOR) 1 CWA746205 ←
25 LEAD WIRE - PCB ECO 1 CWA67C9160 ←
26 CONTROL BOARD CASING FOR PCB ECO 1 CWD93C1108 ←
28 DISCHARGE GRILLE COMPLETE 1 CWE20C3123 ←
29 VERTICAL VANE 11 CWE241350 ←
30 CONNECTING BAR 1 CWE261152 ←
31 CONNECTING BAR 1 CWE261216 ←
32 CONNECTING BAR 1 CWE261215 ←
33 CONNECTING BAR 1 CWE261217 ←
34 AIR SWING MOTOR 1 CWA981264 ←
34a AIR SWING MOTOR 1 CWA98K1015 ← O
35 HORIZONTAL VANE 1 CWE24C1365 ←
36 CAP - DRAIN TRAY 1 CWH521096 ←
37 CONTROL BOARD TOP COVER 1 CWH131350 ←
38 CONTROL BOARD FRONT COVER 1 CWH13C1183 ←
39 REMOTE CONTROL COMPLETE 1 CWA75C3710 ← O
40 FRONT GRILLE COMPLETE 1 CWE11C4820 ← O
41 INTAKE GRILLE COMPLETE 1 CWE22C1678 ← O
42 GRILLE DOOR 1 CWE14C1029 ←
43 E-ION FILTER 2 CWD00K1016 ←
44 SCREW - FRONT GRILLE 2 XTT4+16CFJ ←
45 CAP - FRONT GRILLE 2 CWH521194 ←
46 DRAIN HOSE 1 CWH851173 ←
47 BAG COMPLETE - INSTALLATION SCREW 1 CWH82C1705 ←
48 INSTALLATION PLATE 1 CWH361097 ←
49 FULCRUM 1 CWH621102 ←
To Next Page
