• e-ion Check Mode
o e-ion abnormality check mode
o Purpose is to improve sensor serviceability when sensor is malfunction.
(1) Control starting condition
When all of the conditions are formed
Not in Patrol Demo mode.
e-ion operation ON.
When e-ion check mode signal is received; the procedure of selection is as shown:
• Press “Set” button continuously for 15 seconds by using pointer to enter internal setting mode.
• Press “Timer Decrement" button to select “CHC”.
• Confirm setting by pressing “Timer Set” button, a “beep” sound will be heard.
SET
SET
Transmit Patrol default OFF/ON code
(Buzzer: OFF:Long Beep, ON:Short Beep)
Press continously for 15s
SET
Transmit Patrol demo code
(Buzzer: OFF:Long Beep, ON:Short Beep)
SET
Transmit ECO demo code
(Buzzer: OFF:Long Beep, ON:Short Beep)
SET
Transmit check code
(Buzzer:Short Beep)
o If abnormal discharge is detected at filter (short-circuited) due to water or dust adhesion, etc., the e-ion
indicator blinks immediately.
