9
Type Propeller Fan Propeller Fan
Material PP Resin PP Resin
Motor Type Induction (6 poles) Induction (6 poles)
Input Power W 116 - 122 116 - 122
Output Power W 75 75
Lo rpm 460 - 490 460 - 490
Outdoor Fan
Speed
Hi rpm 815 - 830 815 - 830
Moisture Removal L/h (Pt/h) 2.9 (6.1) 4.0 (8.5)
QLo m
3
/min (ft
3
/min)
Cooling: 11.60 (409)
Heating: 11.60 (409)
Cooling: 12.90 (455)
Heating: 12.90 (455)
Lo m
3
/min (ft
3
/min)
Cooling: 13.00 (459)
Heating: 14.00 (494)
Cooling: 14.30 (505)
Heating: 15.60 (551)
Me m
3
/min (ft
3
/min)
Cooling: 14.60 (515)
Heating: 14.60 (515)
Cooling: 16.20 (572)
Heating: 16.20 (572)
Hi m
3
/min (ft
3
/min)
Cooling: 16.40 (579)
Heating: 17.10 (604)
Cooling: 18.60 (657)
Heating: 20.00 (706)
Indoor Airflow
SHi m
3
/min (ft
3
/min) Cooling: 17.10 (604) Cooling: 20.00 (706
Lo m
3
/min (ft
3
/min) 28.6 (1010) - 30.5 (1080) 28.6 (1010) - 30.5 (1080)
Outdoor
Airflow
Hi m
3
/min (ft
3
/min) 50.7 (1790) - 51.7 (1830) 50.7 (1790) - 51.7 (1830)
Control Device Capillary Tube Capillary Tube
Refrigerant Oil cm
3
Suniso 4GDID or ATMOS NM56M (700) Suniso 4GDID or ATMOS M60 (1130)
Refrigeration
Cycle
Refrigerant Type g (oz) R22, 1710 (60.4) R22, 2050 (72.4)
Height(I/D / O/D) mm (inch) 290 (11-7/16) / 750 (29-17/32) 290 (11-7/16) / 750 (29-17/32)
Width (I/D / O/D) mm (inch) 1070 (42-5/32) / 875 (34-15/32) 1070 (42-5/32) / 875 (34-15/32)
Dimension
Depth (I/D / O/D) mm (inch) 235 (9-9/32) / 345 (13-19/32) 235 (9-9/32) / 345 (13-19/32)
Weight Net (I/D / O/D) kg (lb) 12 (26) / 57 (126) 12 (26) / 60 (132)
Pipe Diameter (Liquid / Gas) mm (inch) 6.35 (1/4) / 12.7 (1/2) 6.35 (1/4) / 15.8 (5/8)
Standard length m (ft) 5 (16.4) 5 (16.4)
Length range (min – max) m (ft) 3 ~ 25 (9.8 ~ 82.0) 3 ~ 25 (9.8 ~ 82.0)
I/D & O/D Height different m (ft) 20.0 (65.6) 20.0 (65.6)
Additional Gas Amount g/m (oz/ft) 20 (0.2) 30 (0.3)
Piping
Length for Additional Gas m (ft) 7.5 (24.6) 7.5 (24.6)
Inner Diameter mm 12 12
Drain Hose
Length mm 560 560
Fin Material Aluminium (Pre coated) Aluminium (Pre coated)
Fin Type Slit Fin Slit Fin
Row x Stage x
FPI
2 x 15 x 21 2 x 15 x 21
Indoor Heat
Exchanger
Size (W x H x L) mm 810 x 315 x 25.4 810 x 315 x 25.4
Fin Material Aluminium (Blue coated) Aluminium (Blue coated)
Fin Type Corrugated Fin Corrugated Fin
Row x Stage x
FPI
2 x 28 x 17 2 x 28 x 17
Outdoor Heat
Exchanger
Size (W x H x L) mm 44 x 711.2 x 782.4:816.9 44 x 711.2 x 782.4:816.9
Material Polypropelene Polypropelene
Air Filter
Type One-touch One-touch
Power Supply Indoor Indoor
Power Supply Cord A 16 20
Thermostat - -
Protection Device Inner Protector Inner Protector
