Indoor CS-A18PKD CS-A24PKD
Model
Outdoor CU-A18PKD CU-A24PKD
QLo m
3
/min (ft
3
/min)
Cooling: 12.0 (425) - 12.0 (425)
Heating: 12.7 (447) - 12.7 (447)
Cooling: 13.5 (477 ) - 13.5 (477)
Heating: 14.2 (503) - 14.2 (503)
Lo m
3
/min (ft
3
/min)
Cooling: 13.2 (467) - 13.2 (467)
Heating: 13.8 (489) - 13.8 (489)
Cooling: 14.7 (520) - 14.7 (520)
Heating: 15.4 (545) - 15.4 (545)
Me m
3
/min (ft
3
/min)
Cooling: 14.5 (514) - 14.5 (514)
Heating: 14.4 (507) - 14.4 (507)
Cooling: 16.3 (577) - 16.3 (577)
Heating: 15.9 (563) - 15.9 (563)
Hi m
3
/min (ft
3
/min)
Cooling: 16.4 (579) - 16.4 (579)
Heating: 17.1 (604) - 17.1 (604)
Cooling: 18.6 (657) - 18.6 (657)
Heating: 20.0 (706) - 20.0 (706)
Indoor Airflow
SHi m
3
/min (ft
3
/min) Cooling: 17.3 (612) - 17.3 (612) Cooling: 20.5 (723) - 20.5 (723)
Outdoor Airflow Hi m
3
/min (ft
3
/min) 50.0 (1770) - 51.0 (1800) 50.7 (1790) - 51.7 (1830)
Control Device Capillary Tube Capillary Tube
Refrigerant Oil cm
3
ATMOSNM56M or SUNISO 4GDID (700) ATMOS M60 or SUNISO 4GDID (1130)
Refrigeration
Cycle
Refrigerant Type g (oz) R22, 1.60k (56.5) R22, 2.05k (72.4)
Height (I/D / O/D) mm (inch) 290 (11-7/16) 695 (27-3/8) 290 (11-7/16) 750 (29-17/32)
Width (I/D / O/D) mm (inch) 1070 (42-5/32) 875 (34-15/32) 1070 (42-5/32) 875 (34-15/32)
Dimension
Depth (I/D / O/D) mm (inch) 240 (9-15/32) 320 (12-5/8) 240 (9-15/32) 345 (13-19/32)
Weight Net (I/D / O/D) kg (lb) 12 (26) 55 (121) 12 (26) 60 (132)
Pipe Diameter (Liquid / Gas) mm (inch) 6.35 (1/4) / 12.70 (1/2) 6.35 (1/4) / 15.88 (5/8)
Standard length m (ft) 5.0 (16.4) 5.0 (16.4)
Length range (min – max) m (ft) 3 (9.8) ~ 25 (82.0) 3 (9.8) ~ 25 (82.0)
I/D & O/D Height different m (ft) 20 (65.6) 20 (65.6)
Additional Gas Amount g/m (oz/ft) 20 (0.2) 30 (0.3)
Piping
Length for Additional Gas m (ft) 7.5 (24.6) 7.5 (24.6)
Inner Diameter mm 16.7 16.7
Drain Hose
Length mm 650 650
Fin Material Aluminium (Pre Coat) Aluminium (Pre Coat)
Fin Type Slit Fin Slit Fin
Row × Stage × FPI 2 × 15 × 17 2 × 15 × 17
Indoor Heat
Exchanger
Size (W × H × L) mm 810 × 315 × 25.4 810 × 315 × 25.4
Fin Material Aluminium (Blue Coat) Aluminium (Blue Coat)
Fin Type Corrugate Corrugate
Row × Stage × FPI 2 × 26 × 17 2 × 28 × 17
Outdoor Heat
Exchanger
Size (W × H × L) mm 660.4 × 796.7 × 831.3 44 × 711.2 × 782.4:816.9
Material Polypropelene Polypropelene
Air Filter
Type One-touch One-touch
Power Supply Indoor Indoor
Power Supply Cord A 16 20
Thermostat – –
Protection Device – –
Dry Bulb Wet Bulb Dry Bulb Wet Bulb
Maximum °C 32 23 32 23
Cooling
Minimum °C 16 11 16 11
Maximum °C 30 – 30 –
Indoor
Operation
Range
Heating
Minimum °C 16 – 16 –
Maximum °C 43 26 43 26
Cooling
Minimum °C 16 11 16 11
Maximum °C 24 18 24 18
Outdoor
Operation
Range
Heating
Minimum °C -5 -6 -5 -6
1. Cooling capacities are based on indoor temperature of 27°C Dry Bulb (80.6°F Dry Bulb), 19.0°C Wet Bulb (66.2°F Wet Bulb) and outdoor air
temperature of 35°C Dry Bulb (95°F Dry Bulb), 24°C Wet Bulb (75.2°F Wet Bulb)
2. Heating capacities are based on indoor temperature of 20°C Dry Bulb (68°F Dry Bulb) and outdoor air temperature of 7°C Dry Bulb (44.6°F
Dry Bulb), 6°C Wet Bulb (42.8°F Wet Bulb)
3. Specifications are subjected to change without prior notice for further improvement.
