Panasonic CS-A9PKD Service Manual

9
Indoor CS-A28PKD
Model
Outdoor CU-A28PKD
Performance Test Condition NEW JIS
Phase, Hz Single, 50
Power Supply
V 220 230
kW 8.00 8.00
BTU/h 27300 27300
Capacity
kJ/h 28800 28800
Running Current A 13.2 12.7
Input Power W 2.86k 2.88k
W/W 2.80 2.78
EER
Btu/hW 9.55 9.48
Power Factor % 98 99
dB-A 49 / 44
Indoor Noise (H / L)
Power Level dB 65 / –
dB-A 55 / –
Cooling
Outdoor Noise (H / L)
Power Level dB 70 / –
kW 8.80 8.80
BTU/h 30000 30000
Capacity
kJ/h 31680 31680
Running Current A 13.1 12.6
Input Power W 2.84k 2.86k
W/W 3.10 3.08
EER
Btu/hW 10.56 10.49
Power Factor % 99 99
dB-A 48 / 44
Indoor Noise (H / L)
Power Level dB 64 / –
dB-A 55 / –
Heating
Outdoor Noise (H / L)
Power Level dB 71 / –
Max Current (A) / Max Input Power (W) 16.4 / 3.45k
Starting Current (A) 40
Type Hermetic Motor / Rotary
Motor Type Induction (2 poles)
Compressor
Output Power W 2.4k
Type Cross-Flow Fan
Material ASG30K1
Motor Type DC / Transistor (8 poles)
Input Power W 94.8 - 94.8
Output Power W 40
QLo rpm
Cooling: 1110
Heating: 1180
Lo rpm
Cooling: 1200
Heating: 1270
Me rpm
Cooling: 1320
Heating: 1320
Hi rpm
Cooling: 1470
Heating: 1520
Indoor Fan
Speed
SHi rpm Cooling: 1520
Type Propeller Fan
Material PP
Motor Type AC / Induction (6 poles)
Input Power W 146.7 - 154.9
Output Power W 80
Lo rpm 460 - 490
Outdoor Fan
Speed
Hi rpm 840 - 855
Moisture Removal L/h (Pt/h) 4.7 (9.9)
