Panasonic CS-C18JKV

5
2 Specifications
MODEL INDOOR CS-C18JKV CS-C24JKV
OUTDOOR CU-C18JKV CU-C24JKV
Performance Test Condition NEW JIS NEW JIS
Power Supply
Phase, Hz Single, 60 Single, 60
V 220 220
Cooling
Capacity
kW 5.30 7.03
BTU/h 18100 24000
kJ/h 19100 25300
Running Current A 8.0 12.0
Input Power W 1.72k 2.55k
EER
W/W 3.08 2.76
BTU/hW 10.52 9.41
Power Factor % 98 97
Indoor Noise (H / L) dB-A 42 /37 46 / 40
Outdoor Noise (H / L) dB-A 54 55
Max Current (A) / Max Input Power (W) 10.6 / 2.20k 14.3 / 2.87k
Starting Current (A) 47.0 63.0
Compressor
Type Hermetic Motor Hermetic Motor
Motor Type Induction (2-poles) Induction (2-poles)
Output Power W 1.2k 1.8k
Indoor Fan
Type Cross-flow Fan Cross-flow Fan
Material ASG30K1 ASG30K1
Motor Type DC motor DC motor
Input Power W 94.8 94.8
Output Power W 40 40
Speed
QLo rpm 670 750
Lo rpm 1020 1110
Me rpm 1110 1230
Hi rpm 1200 1350
SHi rpm 1370 1500
Outdoor Fan
Type Propeller Fan Propeller Fan
Material PP Resin PP Resin
Motor Type Induction (6-poles) Induction (6-poles)
Input Power W 162.8 160.1
Output Power W 69 72
Speed
Hi rpm 810 820
Lo rpm — 490
Moisture Removal L/h (Pt/h) 2.9 (6.1) 4.0 (8.5)
Indoor Airflow
QLo
m
3
/min (ft
3
/min)
8.9 (313) 10.1 (357)
Lo
m
3
/min (ft
3
/min)
13.4 (474) 15.0 (528)
Me
m
3
/min (ft
3
/min)
14.6 (516) 16.6 (585)
Hi
m
3
/min (ft
3
/min)
15.8 (558) 18.2 (642)
SHi
m
3
/min (ft
3
/min)
18.0 (637) 20.2 (713)
Outdoor Airflow Hi
m
3
/min (ft
3
/min)
51.0 (1800) 51.0 (1800)
Refrigerant Cycle
Control Device Capillary Tube Capillary Tube
Refrigerant Oil
cm
3
ATMOS M60 or SUNISO 4GDID (450) ATMOS M60 or SUNISO 4GDID (450)
Refrigerant Type g (oz) R22, 1.33k (46.9) R22, 1.41k (49.8)
Dimension Height (I/D / O/D) mm (inch) 290 (11 - 7/16) 750 (29 - 17/32) 290 (11 - 7/16) 750 (29 - 17/32)
Width (I/D / O/D) mm (inch) 1070 (42 - 5/32) 875 (34 - 15/32) 1070 (42 - 5/32) 875 (34 - 15/32)
Depth (I/D / O/D) mm (inch) 235 (9 - 9/32) 345 (13 - 19/32) 235 (9 - 9/32) 345 (13 - 19/32)
Weight Net (I/D / O/D) kg (lb) 12.0 (26) 48.0 (106) 12.0 (26) 60 (132)
