REMINDER - To reinstall the Fan Motor, put it back in place, adjust
the position of the Fan Motor’s leadwire appropriately as shown
in the Fig. 8 before installing the Cross Flow Fan.
Fig. 9
Fig. 10
12.6. Outdoor Electronic Controller Removal Procedure
1. Remove the top panel and front panel
Fig. 16
-Be save to return the wiring to its original position
-There are many high voltage components within the heat sink
cover so never touch the interior during operation. Wait at least two
minutes after power has been turned off.
To Next Page
