Panasonic CS-HZ25UKE Service Manual

17
5. Location of Controls and Components
5.1 Indoor Unit
Front panel
Air Filters
Horizontal airflow direction louver
• Do not adjust by hand.
Auto OFF/ON button
Remote Control Receiver
(Maximum distances: 8m)
• Use when remote control is misplaced or
a malfunction occurs.
Vertical airflow
direction louver
• Do not adjust
by hand.
Indicator
Aluminium fin
5.2 Outdoor Unit
Air inlet (rear)
A
ir outlet
Air inlet (side)
5.3 Remote Control
+8/15° Heat Operation
Operation mode
Check
Timer setting
Wireless LAN features
Temperature setting
Fan speed selection
Clock setting
Airflow direction adjustment
Remote control display
POWERFUL / QUIET operation
nanoe X operation
OFF/ON
